Type: UNPROPELLED BARGE
Year of Built: 2002
Place of Built: Naples ITALY
Length: 35.7 Meters
Beam Max: 10.2 Meters
Draft: 4 Meters
DWT: 1000 T
Class: RINA
Speed: N/A

• CARGO TANKS:
• N 8 CARGO TANKS FOR FUEL AND DIESEL OIL N 3 CARGO TANKS FOR LUBOIL TOTAL CAPACITY 1106 M3
• BALLAST TANK:
• ALL COMPLETELY EPOXY COATED (INTERNATIONAL PAINT) HEATING COILS IN ALL FUEL
  CARGOTANKS
• CARGO PUMPS:
• N 1 INDIPENDENT ENGINE DRIVING GEAR PUMPS TYPE WORTHINGTON 200 M3/H AT 80 MHD FOR FUEL OILN 1 COMPLETE ARRANGEMENT FOR AN INDIPENDENT ENGINE DRIVING GEAR PUMPS 200M3/H AT 80 MHD FOR DIESEL OIL

• HOSE CRANE:

N 1 ELECTRO/HYDRAULIC - 1 T AT 12 M CRANES RADIUS

• CARGO MANIFOLD:

LOADING/UNLOADING VIA MIDSHIP MANIFOLDS AND STERN MANIFOLDS

• ANTIPOLLUTION EQUIPMENT:

80 M ANTIPOLLUTION COASTAL BOOMS ON E/DRIVEN DRUM ON MAIN DECK 300 M OIL SORBENTS

• ACCOMODATION:

1 CABIN FOR CRE REFUGE - CARGO PUMPS MAIN PANEL CONTROL - ONE TOILET


Price: On Application
